VELUX EFL MK06 0022B Twin Vertical Combination Slate Flashing 78x118cm

  • Icons


    10 years

  • Icons

    Roof Pitch


  • Icons

    Slate Profile

    Up to 8mm



£259.38 inc. VAT

Multibuy discount

  • 1+ £216.15
  • 2+ £209.80
  • 4+ £203.45
  • 7+ £197.15
Product Code:
EFL MK06 0022B
up to 16 working days
Size (W x H):

Product Description

The VELUX EFL 0022B twin slate flashing is suitable for slates up to 8mm thick and suitable for vertical combinations only. This flashing is used for installing two VELUX roof windows and two VELUX vertical elements side-by-side with an 18mm gap.

VELUX flashings integrate with the roof covering to provide a weather-tight finish around the window. They are compatible with any slate (up to 8mm thick), but not interlocking. Window flashings are designed to sit under the roofing materials, and then the water from the roof is collect in the built-in guttering system. The gutter overlaps a second section of the flashing to help the water flow smoothy down the side of the window. The flashing apron moulds to the roof material profile to allow the water to drain away.

  • Flashings for installing two roof windows and two vertical element side-by-side into slate up to 8mm thick
  • For roof pitches from 15° - 55°
  • Not for interlocking slate or thatch
  • Maintenance free grey aluminium as standard.

Product Specification

Combination Flashings Twin
Compatible Roof Material(s) Slate
External Finish Grey
Guarantee 10 years
Roof Pitch 15-55°
Size (W x H) 78 x 118cm
Slate Profile Up to 8mm
Style Vertical combination
